Chassis Paint Black Satin CIO Chassis In One 2

Product Details

Overview

Buzzweld CIO (Chassis In One) is a high-adhesion corrosion stabilising primer and top coat in one, designed for customers seeking a simple, long-term solution for chassis and underbody protection. The CIO system requires just two coats to protect your chassis when brush or Schutz applied, making it significantly faster and more cost-effective than traditional multi-stage systems.

Key Benefits

1. Extreme Abrasion Resistance: Contains self-leafing glass flake for superior abrasion resistance compared to standard coatings
2. Double Acting on Rust: The only coating in the world we are aware of that is both rust stabilising AND high in zinc content
3. Corrosion Prevention: Contains corrosion inhibiting pigment for class-leading rust prevention by stabilising corrosion and preventing it from continuing to form
4. Fast Over-Coating: Over-coating times as little as 30 minutes - no breaks required between coats in most situations
5. Time & Cost Savings: Primer and top coat in one saves significant time and money while outlasting most competing products
6. OEM Appearance: Satin lustre finish for original equipment manufacturer look
7. Designed for Hand-Prepared Steel: Formulated from the ground up for practical application scenarios
8. Direct-to-Rust Application: Suitable for over-painting firmly adherent existing rust

Applications

Ideal for:

• Chassis and underbody protection
• Hand-prepared steel surfaces
• Firmly adherent existing rust
• Areas requiring fast turnaround protection
• Bedliner or anti-slip coating applications
• Surfaces requiring both primer and top coat

Product Variants

Standard CIO

High-performance rust stabilising primer and top coat in one with all benefits listed above.

Platinum Upgrade

The highest grade of CIO available. Infused with advanced compounds providing:

1. Sound Deadening - Limits sound transfer through treated surfaces
2. Resonance Suppression - Actively combats panel resonance
3. Thermal Insulation - Significantly limits heat loss and reduces energy required for climate control
4. Enhanced Ceramic Properties - More resistant to abrasion and gouging with increased longevity
5. Increased Porosity Resistance - Extended service life

For ultimate sound and thermal insulation, apply CIO Platinum over Cosyfoam.

Container Options

1000ml Paint Tin
Standard paint tin for brush, roller, or spray gun application (can be thinned)

1000ml Schutz Undercoating Tin
Stubby Schutz tin compatible with FX10 and FX11 spray guns - gun screws directly onto tin. For use with standard Schutz guns, trim the pickup tube 75mm shorter.

5000ml Paint Tin
Larger format paint tin for brush, roller, or spray gun application (can be thinned)

400ml Traditional Aerosol
Standard aerosol format

400ml Buzzweld Powercan
Professional aerosol using NO THINNER - outputs the same amount of paint as a spray gun, resulting in fewer coats, higher film build, and time savings. Empties quickly due to concentrated output. Spray from further away than traditional aerosols. Includes two nozzles and can also be used as a textured bedliner spray.

Application Methods

• Spray neat using High Pressure Underbody Gun
• Spray thinned using conventional spray equipment
• Brush or roller application
• Use as bedliner or anti-slip coating

Coverage Guide

Aerosol Application (minimum 3 coats)

• 1 can per wheel arch
• 8 cans for a small chassis
• 14-20 cans for a large chassis

Tinned Product (minimum 2 coats)

• Smooth surfaces: 6m² per 1000ml
• Rough substrate (no primer): 4m² per 1000ml
• Chassis and axles (up to 110 size, not pitted/rough profile): 5000ml (2500ml if primed)
• Per wheel arch (two coats): 350ml

Application Instructions

Standard Application:

• For optimal application, ensure the product is at room temperature (15-20°C) before use
• Two coats required for brush/Schutz application
• Over-coating time: as little as 30 minutes between coats
• Can be applied over firmly adherent existing rust

Aerosol Application Direct-to-Rust/Steel:

• Apply 4-5 coats for long-term protection (due to shrinkback from aerosols)
• Ideally stripe coat for comprehensive coverage
• Read guides prior to use

Technical Information

System: Rust stabilising primer and top coat in one

Finish: Satin lustre (OEM appearance)

Over-Coating Time: As little as 30 minutes

Recommended Coats: 2 coats (brush/Schutz), 4-5 coats (aerosol direct-to-rust)

Composition: Self-leafing glass flake, high zinc content, corrosion inhibiting pigment

Rust Compatibility: Suitable for firmly adherent existing rust

Thinning: Use Buzzweld 1K Multi-Thinner when thinning is required

Note: Drums and colours are non-returnable

Data Sheet: Available for detailed technical specifications

Related Products

• Cosyfoam - for maximum thermal and sound insulation when used under CIO Platinum
• High Pressure Underbody Gun - for neat spray application
